Devialet Phantom Ultimate / 108 dB

Devialet Phantom Ultimate / 108 dB - Activ High-End HiFi-loudspeaker

Implosive sound
In a class of its own: 108 dB SPL. 14 Hz - 35 kHz (+/- 6 dB). 1100 W.

The Devialet Phantom Ultimate 108 dB loudspeaker impresses with its characteristic Devialet sound, seamless stereo pairing and powerful design.

Intuitive and with numerous connection options, the Devialet Phantom Ultimate 108 dB impresses with its unbridled music playback. The active high-end hi-fi speaker reveals the physical impact of high-end sound with more power, clarity and precision than any other wireless speaker.

We have developed a sophisticated and reliable software architecture. Under its housing, the Devialet Phantom Ultimate speaker combines an NXP iMX8 processor with the latest Devialet DOS3 operating system, allowing you to play your music with ease.

Experience seamless integration with high-resolution streaming protocols such as AirPlay, Google Cast, Roon, Spotify Connect, UPnP and TIDAL Connect. The connectivity options go even further with Bluetooth® 5.3 and Wi-Fi 6, ensuring extremely low latency, improved stability and cross-device streaming.

And this optimised experience continues in the Devialet app with unique personalisation options. A six-band equaliser ensures optimal audio reproduction, while three special audio modes enable different sound experiences:

• Music mode: Your music – just as the artist intended.
• Cinema mode: Cinema-quality sound, home-style comfort.
• Podcast mode: Every episode sounds as if it were recorded in your living room.

For a perfectly balanced sound experience, Bass Reducer, Loudness and Adaptive Volume Level (AVL™) enable precise control of sub-bass, volume and dynamics.

Unleash the potential:
The position and orientation of your Devialet Phantom Ultimate speaker can make all the difference. For optimal listening pleasure:

• Height: Position the speaker between 45 and 90 cm above the floor for optimal effect.
• Distance from the wall: Leave at least 30 cm between the speaker and the wall so that the bass frequencies are reflected naturally and the depth effect is enhanced.
• Keep the area in front of the speaker(s) clear to ensure unobstructed sound propagation.
• Position the speaker at a distance of 1.5 to 2.5 metres from your listening position to ensure an optimal sound experience.
• In a stereo setup, both speakers should be placed 1.5 to 2.5 metres apart and angled inwards at 25 to 30° to create a lively, lifelike sound image.

See the movement:
When the Devialet Phantom Ultimate awakens, you don't just hear it, you can see it. Beneath its flawless curves, a force is unleashed that propels the sound forward with full force. Press play and the bass sets in motion a captivating movement that vibrates in time with every single note. This is precision in its purest form: raw power meets sculptural elegance, and the two combine to form a harmonious whole. Hidden inside, convex low-frequency membranes amplify the sound pressure and volume, immersing you even deeper into the sound. An acoustic and visual experience so overwhelming that it doesn't just fill the room. It makes your very core tremble.

Distinctive and iconoclastic.
In a completely unique way, it incorporates groundbreaking technologies for an intense listening experience that you can literally feel deep in your body and soul.

Sound that moves
Implosive, adj. Describes an extreme internal reaction. The sound of the Phantom I in one word? Implosive. 1,431 specially crafted parts work in harmony to create an internal reaction, both in the Phantom and in you. From infrabass to extremely clear highs, unleash the physical impact of high-quality, ultra-dense sound with power, clarity and precision like you've never experienced before. Simply unmistakable!

Devialet Intelligence Processor
Phantom contains our powerful next-generation signal processing chip, which contributes to better sound quality. Phantom's signal processing and amplifier performance (ADH®, SAM®, Magic Wire, Class A, DAC) is embedded in a SoC (System on a Chip) designed specifically for optimal integration. The result? Improved heat dissipation for optimal performance at any volume, better energy efficiency, and virtually no measurable distortion, saturation, or noise.

High resolution
Phantom now combines industry-leading sound technology with high resolution to provide a unique listening experience for a wide audience. In addition to UPnP and optical input, we are delighted that Phantom is now Roon Ready, offering all Phantom users unique 24-bit hi-res audio.

Technological skills
Devialet thrives on innovation in all areas (hardware, software, interior and exterior design) in order to continuously offer better acoustics.

ADH® Analog Digital Hybrid:
Analogue meets digital
Next-generation Devialet ADH® (Analogue-Digital Hybrid) technology offers the best of both worlds, delivering sound in its most electrifying form – with lower power consumption and crystal-clear frequencies up to 35 kHz.
ADH, a patented invention by Devialet, is a revolution in the world of amplification, combining the sophistication of analogue amplification with the power and compactness of digital amplification. It amplifies the sound signal with unparalleled purity and transparency.

SAM® Speaker Active Matching:
We developed the mathematical SAM® model to ensure flawless fidelity throughout playback. Whether dealing with transients or steady signals, the amount of information processed by SAM® exceeds anything previously thought possible. Phantom can reproduce the exact rhythm and tempo of your music with absolute precision. This allows you to feel every single emotion, true to the original.

HBI® Heart Bass Implosion:
A bass you can feel deep inside HBI® (Heart Bass Implosion) pushes the boundaries of infra-bass, reaching depths of up to 14 Hz in an extremely compact form. Two perfectly synchronised side woofers work in unison to eliminate unwanted vibrations – for pure sound.

AVL - Adaptive Volume Level:
Don't miss a single detail, no matter how small. Devialet's Adaptive Volume Level (AVL™) technology uses dynamic real-time equalisation to deliver a smoother, more balanced listening experience. From explosive action to whispered dialogue, you won't miss a thing.

At the heart of the Phantom are two sealed bass speakers that are compact and operate under high pressure. The powerful sideways movement of these speakers produces a sound with unparalleled physical impact, extending into the infra-bass range (14Hz).

Devialet Phantom specifications Ultimate
Maximaler Schallpegel

• 108 dB SPL in 1 m Abstand

Verstärkungskraft:

• 1100 W RMS

Frequenzbereich (Bandbreite)

• Frequenzbandbreite: 14Hz bis 35kHz (+/- 6 dB)
• Präzision des Frequenzverhaltens: ± 2dB von 20Hz bis 20kHz

Lautsprecher

• Hochton-Lautsprecher mit Aluminiumkuppel (new-gen)
• Mittelton-Lautsprecher mit Aluminiumkuppel (new-gen)
• Tiefton-Lautsprecher mit Aluminiumkuppel (new-gen)

Seitenverkleidung

• Body: Light Pearl Gehäuse: ultra-matte Lackierung - PANTONE 9102C
• Seitenteile: Kunststoff - hochglanzpoliert - PVD PANTONE METAL 8380C

Konnektivität der Devialet Phantom Ultra

• WiFi 6 (2.4 GHz und 5 GHz)
• AirPlay 2
• Bluetooth 5.3 (SBC und AAC-Codecs)
• Spotify Connect - Lossless-kompatibel
• Tidal Connect
• Google Cast
• UPnP
• Optical Cable
• Roon Ready (RAAT)

Lieferumfang

• 1 x Phantom Ultimate Aktiv-Lautsprecher
• 1 x Power cable
• Documentation

Stromverbrauch
AUS: < 0,5 W
STAND-BY: < 2 W

Input
Bis zu 24 bit / 192 kHz

DSP
32 bit / 96 kHz

Prozessor
SoC NXP i.MX 8M Nano
4 x 1.5 GHz
